Panasonic Modular Chip Mounter NPM-W2S

Performance & Technical Highlights

Maximum Speed: 86,000 cph
• WXS 16-nozzle Head X 2: 43,000 + 43,000 cph
• WXS 8-nozzle Head X 2: 23,000 + 23,000 cph
• WX 4-nozzle Head X 2: 9,400 + 9,400 cph
• WX 3-nozzle Head X 2: 8,400 + 8,400 cph

Component Dimensions:
• 16-nozzle Head: 03015 / 0402 chip to L 6 × W 6 × T 3
• 8-nozzle Head: 0402 chip to L 45 × W 45 or L 100 × W 40 × T 12
• 4-nozzle Head: 0603 chip to L 120 × W 90 or L 150 × W 25 × T 30

Placement Accuracy:
• WXS 16-nozzle Head: ±25µm / chip
• WXS 8-nozzle Head: ±25µm / chip
• WX 4-nozzle Head: ±20µm / chip
• WX 3-nozzle Head: ±20µm / chip

PCB Dimensions:
• Dual-lane mode: L 750 mm × W 610 mm
• Single-lane mode: L 750 mm × W 300 mm

Feeder Capacity: Max. 136 (4-8 mm tape reel)

💡 Looking for bulk orders or specialized SMT one-stop solutions? Contact our 24/7 technical support team today for a fast quote!

Add to Inquiry Cart

Our Services

We go beyond delivering powerful machinery to provide a complete partnership built on expertise and unwavering support. Our service ecosystem is designed to ensure maximum uptime, productivity, and return on your investment.

1.Pre-Sales Technical Support

1.1 Technical consultation & line layout planning 1.2 Demo machine testing with customer materials 1.3 Pre-sales training for technical team

2. Delivery & Commissioning

2.1 Professional installation & calibration 2.2 Parameter optimization for specific PCBs 2.3 Trial production validation 2.4 Operator training (SOP, maintenance, troubleshooting) 2.5 Acceptance test with performance verification

3. After-Sales Support

3.1 1-year standard warranty (extendable) 3.2 7×24 hotline, 4-hour emergency response 3.3Scheduled preventive maintenance (quarterly/half-yearly) 3.4 Genuine spare parts supply 3.5 Remote diagnosis & software updates

4. Value-Added Services (Optional)

4.1 Performance upgrades (software/hardware) 4.2 Production efficiency optimization analysis 4.3 Advanced technical training programs 4.4 Extended warranty (2-3 years) 4.5 Equipment relocation service

Our Promise

We are dedicated to being a true partner in your success, providing the tools, knowledge, and continuous support necessary to keep your projects moving forward efficiently and profitably.
