SMT Spare Part ASM SIPLACE SmartFeeder 24mm X Splice Sensor 00141393
Specification Data
| Brand | ASM |
| Part Number | 00141393 |
| Description | ASM SIPLACE SmartFeeder24mm X Splice Sensor |
| For | X-Serie |
Highlights:
Assured Quality
- Cost-Saving, Competitive Price
- Minimum Order Quantity: No Limit
- Fast Delivery: 5-7 Days
- Safety Delivery: Well protected package
- Services: 7/24 Guaranteed After-sales Service Service, Products Are Only The Beginning Of A Service, Not The End, Committed To Customer Satisfaction
- All Product Will Be Checked Carefully Before Shipment
- Providing Professional SMT One-stop Solutions
-
+
Add to Inquiry Cart
SIPLACE Tape Feeders X Series
Tape feeder module
Item no.
SIPLACE SmartFeeder 4 mm X
With splice sensor
With splice sensor
00141368
00141388
00141388
SIPLACE SmartFeeder 2 x 8 mm X
With splice sensor
With splice sensor
00141269
00141289
00141289
SIPLACE SmartFeeder 8 mm X
With splice sensor
With splice sensor
00141370
00141390
00141390
SIPLACE SmartFeeder 12 mm X
With splice sensor
With splice sensor
00141371
00141391
00141391
SIPLACE SmartFeeder 16 mm X
With splice sensor
With splice sensor
00141372
00141392
00141392
SIPLACE SmartFeeder 24 mm X
With splice sensor
With splice sensor
00141373
00141393
00141393
SIPLACE SmartFeeder 32 mm X
With splice sensor
With splice sensor
00141374
00141394
00141394
SIPLACE SmartFeeder 44 mm X
With splice sensor
With splice sensor
00141375
00141395
00141395
SIPLACE SmartFeeder 56 mm X
With splice sensor
With splice sensor
00141376
00141396
00141396
SIPLACE SmartFeeder 72 mm X
With splice sensor
With splice sensor
--
00141397
00141397
SIPLACE SmartFeeder 88 mm X
With splice sensor
With splice sensor
--
00141398
00141398
SIPLACE SmartFeeder 104mm X
With splice sensor
With splice sensor
--
00141399
00141399
SIPLACE SmartFeeder 24mm X
Pos.
Item no.
Description
Part marking
1
00141373S01
SIPLACE SMARTFEEDER 24MM X
SPARE PART
2
03110031-02
SIPLACE SMARTFEEDER 24MM X
3
03113047S01
ROCKER X24SMART CPL.
SPARE PART
4
03033796-01
REMFORM-SCREW RF-SN75-2,5 X 6-9.8
STANDARD PARTS
5
03115758-01
STUFF WHEEL GEARED CPL. ROCKER /X24SMART
SPARE PART
6
03003994S01
SLIDE GUIDE /REAR L200
SPARE PART
7
03115792-01
STUFFING WHEEL GEARED CPL. /X24SMART
SPARE PART
8
03115925S01
FLAP FOIL DISPOSAL CPL. X24SMART
SPARE PART
9
00349527-01
ROUND MAGNET 3X4 NEODYMIUM
SPARE PART
10
03042171S01
AXIS FLAP /FOIL CASE X16-X24
SPARE PART
11
03113785-01
FOIL ROCKER UNIT CPL. X24SMART
12
03092093-01
SPRING 0,7X7,5X35,8
SPARE PART
13
03112580S01
ROCKER X24SMART CPL.
SPARE PART
14
03113264-01
CASE ROCKER CPL. X24-104
15
03033796-01
REMFORM-SCREW RF-SN75-2,5 X 6-9.8
STANDARD PARTS
16
03112666S01
HANDLE X24-104 CPL.
SPARE PART
17
00341370S01
BLADE, PARTITION
SPARE PART
18
03033796-01
REMFORM-SCREW RF-SN75-2,5 X 6-9.8
STANDARD PARTS
19
03110042-01
CONTROL PANEL CPL. X24-104
SPARE PART
20
03110763-01
PCB CONTROL PANEL ASSEMBLED X24-104
SPARE PART
21
03115906-01
LEAF SPRING TAPE INFEED X24SMART
SPARE PART
22
03104558-01
DUMMY SPLICE SENSOR X8SMART
SPARE PART
23
03033798-01
REMFORM-SCREW RF-SN75-2,5 X 10-9.8
STANDARD PARTS
24
03012683-01
COMPRESSION SPRING D-027
SPARE PART
25
03043774-01
ADJUSTMENT WASHER /D3.1 D15 T0,1
STANDARD PARTS
26
03068667-01
SHOULDERED SCREW ø4X4,5 M3 /X2X8
SPARE PART
27
03048855-01
PRESSURE SPRING 0.75X6.25X31X8.5
SPARE PART
Pos.
Item no.
Description
Part marking
28
03033796-01
REMFORM-SCREW RF-SN75-2,5 X 6-9.8
STANDARD PARTS
29
03071822-01
SN 213307-H-M2,5 X 5-A2-70
STANDARD PARTS
31
03125222S01
EDIF-SEKUNDARY CPL. X SMART
SPARE PART
32
03023227-01
ISO 7046-2-M2,5 X 5-A2-70-H
33
03063591-01
CABLE PHOTO INTERRUPTER X2X8
SPARE PART
34
03033797-01
REMFORM-SCREW RF-SN75-2,5 X 8-9.8
STANDARD PARTS
35
03113432-02
DRIVE CPL. X24-104SMART
36
03109337-02
MOTOR SUPPORT CPL. X24-104SMART
37
03019604S01
SLIDING FOIL X-FEEDER
SPARE PART
38
03005196-01
ROLL, LOCKING X-SERIES
SPARE PART
39
03015750-01
ISO 8734 - 3 X 10 - A-ST
40
03058808S01
SLIDING GUIDE
SPARE PART
41
03110710-01
BOARD HOLDER W/ BOARD X24-104
42
03082310S01
PCB PHOTO INTERRUPTER ENCODER X12/X16 V2
SPARE PART
43
03033796-01
REMFORM-SCREW RF-SN75-2,5 X 6-9.8
STANDARD PARTS
44
03116587-01
HYBRID STEPPER MOTOR CPL. X24-104SMART
SPARE PART
45
03083184-02
SHIFTED GEAR2 FOIL X12/16
SPARE PART
46
00095481-01
DIN 471-5X0,6-C67
47
00305783-01
DIN 988-5X10X0,1-ST 2 K 50
STANDARD PARTS
48
03023240-01
ISO 7046-2-M3 X 10-A2-70-H
STANDARD PARTS
49
03012488-01
SN 213307-H-M2 X 2.5-A2
50
03071822-01
SN 213307-H-M2,5 X 5-A2-70
STANDARD PARTS
51
00141393-01
SIPLACE SMARTFEEDER 24MM X SPLICE SENSOR
52
03132231-02
SIPLACE SMARTFEEDER 24MM X SPLICE SENSOR
53
03107028S03
SPLICE SENSOR X8SMART CPL.
RETROFIT KIT
